API 5L X70 / L485 LINE PIPE

API 5L x70 , Tubo API 5L Gr X70, and API 5L L485 Steel Pipe is available with some of the manufacturers, Suppliers and exporters in India in Black painting, varnish paint, anti-rust oil, or other coating required. Packaging can be done with the help of Plastic caps on both ends, Steel bundle, or according to customers' request. API 5L x70 material Chemical composition include Si Max 0.55, C max 0.04-0.16, P max 0.035, Mn. Max 1.10-1.70, S max 0.035. Applications of Tubo API 5L gr x70 and L485m Steel Pipe is also known as API 5L x70 Line pipe, fluid pipe, water pipe, structure steel tube, and piling tube.

Supply Range

API 5L X70 Pipe OD Range (Seamless)	1/2 inch - 30 inch 21.3 mm - 762 mm
API 5L X70 Pipe OD Range (ERW)	1/2 inch - 20 inch 21.3mm - 508mm
API 5L X70 Pipe OD Range (LSAW/DSAW)	16 inch - 100 inch 406mm - 2500mm
API 5L 70 Pipe Standard	API 5L X70 (Q, M, N, R, QS, MS), ISO 3183 L485 (API specification 5L - 46th Edition, November 1, 2018)
API 5L X70 Pipe Product Specification Level	PSL1, PSL2, NACE, Sour Service, HIC, SSC, H2 Service
API 5L X70 Pipe Types	Seamless and Welded in ERW, LSAW, DSAW, SSAW (HSAW) .
API 5LX70 Pipe Wall Thickness / Schedule	SCH-20, SCH-40, SCH-STD, SCH-XS, SCH-80, SCH-100, SCH-120, SCH-160, SCH-XXS, HEAVY THICKNESS
API 5L X70 Pipe Pipe Length	SRL (Single Random Length), DRL (Double Random Length), 20Ft (6Mtr), 40Ft (12Mtr), Cut Length
API 5L X70 Pipe Pipe Ends	Plain, Bevel, Screwed, Threaded
API 5L X70 Pipe Coating Finish Types	Bare, Oiled, Mill Varnish, Galvanized, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap End
