API 5L X46 / L320 LINE PIPE

API 5L X46 pipes have minimum yield strength of about 317 MPA. These grade pipes are superior to API 5L Grade B and API 5L Grade X42 pipe concerning chemical and mechanical properties. This grade is known to be heavy-duty and high performance, thus making it economically beneficial. Due to their high mechanical strength, these pipes have robust construction, high cut resistance and precise dimensions. Client’s generally select API 5L Grade PSL1 X46 Pipe where they are seeking better performance than grade B and grade X42 pipes.

Supply Range

API 5L X46 Pipe OD Range (Seamless)	1/2 inch - 30 inch 21.3 mm - 762 mm
API 5L X46 Pipe OD Range (ERW)	1/2 inch - 20 inch 21.3mm - 508mm
API 5L X46 Pipe OD Range (LSAW/DSAW)	16 inch - 100 inch 406mm - 2500MM
API 5L X46 Pipe Standard	API 5L X46/L320(Q, M, N, QS, MS), ISO 3183 L320 (API specification 5L - 46th Edition, November 1, 2018)
API 5L X46 Pipe Product Specification Level	PSL1, PSL2, NACE, Sour Service, HIC, SSC, H2 Service
API 5L X46 Pipe Types	Seamless and Welded in ERW, LSAW, DSAW, SSAW (HSAW) .
API 5L X46 Pipe Wall Thickness / Schedule	SCH-20, SCH-40, SCH-STD, SCH-XS, SCH-80, SCH-100, SCH-120, SCH-160, SCH-XXS, HEAVY THICKNESS
API 5L X46 Pipe Pipe Length	SRL (Single Random Length), DRL (Double Random Length), 20Ft (6Mtr), 40Ft (12Mtr), Cut Length
API 5L X46 Pipe Pipe Ends	Plain, Bevel, Screwed, Threaded
API 5L X46 Pipe Coating Finish Types	Bare, Oiled, Mill Varnish, Galvanized, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap End
