API 5l Gr B L245 Line Pipe

API 5L GR. B / L245 Line Pipe

The API 5L L245 Pipe belongs to the category of those carbon steel seamless pipes which are strictly manufactured as per certain standards and qualifications which are desirably considered as the best one stands up to the mark. The pipes brought up by American petroleum institute contain all the specifications which can meet up with eth client's requirements at its best. These carbon steel pipes come up with some astonishing factors and are provided with the multiple end connections like the external upset ends and the non upset ends.

Specification

API 5L GR. B Pipe Types	Seamless and Welded in ERW, LSAW, DSAW, SSAW (HSAW) .
API 5L GR. B Pipe OD Range (Seamless)	1/2 inch - 30 inch 21.3 mm - 762 mm
API 5L GR. B Pipe OD Range (ERW)	1/2 inch - 20 inch 21.3mm - 508mm
API 5L GR. B Pipe OD Range (LSAW/DSAW)	16 inch - 100 inch 406mm - 2500MM
API 5L GR. B Pipe Standard	API 5L GR. B (Q, M, N, QS, MS), ISO 3183 L245 (API specification 5L - 46th Edition, November 1, 2018)
API 5L GR. B Pipe Product Specification Level	PSL1, PSL2, NACE, Sour Service, HIC, SSC, H2 Service
API 5L GR. B Pipe Wall Thickness / Schedule	SCH-20, SCH-40, SCH-STD, SCH-XS, SCH-80, SCH-100, SCH-120, SCH-160, SCH-XXS, HEAVY THICKNESS
API 5L GR. B Pipe Length	SRL (Single Random Length), DRL (Double Random Length), 20Ft (6Mtr), 40Ft (12Mtr), Cut Length
API 5L GR. B Pipe Ends	Plain, Bevel, Screwed, Threaded
API 5L GR. B Pipe Coating Finish Types	Bare, Oiled, Mill Varnish, Galvanized, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap End
