The technical delivery conditions specified by EN 10297 apply to non-alloy as
well as alloy steels seamless circular tubes. The tubes produced under standard
EN 10297-1 are intended for use in both mechanical and general engineering
applications. Like most English standards, the steels used in standard EN 10297
are designated on the basis of product application, or delivery condition. The
designations of the steel grade for an EN 10297 Tube also makes a mention of its
minimum yield strength. In the case of pipes belonging to grade en 10297-1
e355+ar, the letter E is a designation for steels applied in the manufacture of
machine parts. And the term AR indicates that there is not heat treatment
required for that particular steel grade. For instance, the minimum yield
strength of bs en 10297-1 grade e355 is 355 N/mm2.
.
Property | Value | Unit |
---|---|---|
Grade | E355 | |
Material Type | Seamless Steel Pipe | |
Material Standard | EN 10297-1, EN 10305-1, EN 10305-2 | |
Material Composition | Carbon, Silicon, Manganese, Phosphorus, Sulfur | |
Yield Strength | ≥ 355 MPa | MPa |
Tensile Strength | 490 - 630 MPa | MPa |
Elongation | ≥ 22% (in 200 mm) | % |
Impact Strength | - | |
Charpy V-notch Impact Test | - | |
Applications | Automotive components, hydraulic systems, precision engineering | |
Manufacturing | Hot finished seamless pipes | |
Sizes | Various sizes and thicknesses as per EN standards |
![]() |
![]() |
![]() |
![]() |
